6 1/4" FA517G , TCI Tricone Bit , Rubber Sealed Journal Bearing , IADC 517

Product Categories

FLRT Bit

Contact Now

6 1/4" FA517G , TCI Tricone Bit , Rubber Sealed Journal Bearing , IADC 517

Name: 6 14quot FA517G TCI Tricone Bit Rubber Sealed Journal Bearing IADC 517
Brand: FLRT
Price: 1 USD

Brand Name : FLRT

Model Number : 6 1/4 FA517G

Certification : API-7-1 , ISO 9001:2008

Place of Origin : China

MOQ : 25pcs

Supply Ability : 200pcs per quarter

Delivery Time : 5~45 workdays

Packaging Details : plywood box / iron box

Bearing Type : Rubber Sealed Journal Bearing

Cutting Material : TCI

Standard : API-7-1, ISO 9001:2008

Series : FA

Application 1 : Oil well drilling / Gas well drilling

Application 2 : Geothermal well drilling

IADC : 517

Contact Now

6 1/4" FA517G , TCI Tricone Bit , Rubber Sealed Journal Bearing , IADC 517

PRODUCT SPECIFICATIONGS

Bit Size: 6 1/4 inch (158.8mm)

IADC: 517

SERIES: FA

Tooth type: ( TCI ) Tungsten Carbide Insert

Connection 3 1/2 inch API REG PIN

Nozzle Three jet(side) nozzles,

Bit Weight: 14kgs

6 1/4" FA517G , TCI Tricone Bit , Rubber Sealed Journal Bearing , IADC 517

SIZE AVAILABLE

Form 7 7/8inch to 17 1/2inch

RECOMMENDED DRILLING PARAMETERS FOR APPLICATION

Types & IADC Code		117	127	437 447	517 527	537 547	617 627	637
WOB	KN/mm(Bit Dia.)	0.35~0.8	0.35~0.9	0.35~0.9	0.35~1.0	0.45~0.95	0.45~1.1	0.5~1.1
WOB	Lb/in. (Bit Dia.)	2000~4271	2000~5142	2000~5142	2000~5714	2571~5714	2571~6285	2857~6285
Rotation Speed (Rpm)		240~80	240~70	180~80	220~60	220~50	200~50	180~40

The above chart represents commonly available sizes and types, we do produce other sizes and types of rock bits which do not appear on this list. Please contact us for more information.
